Applications
Where our RGB LED Analyser is commonly used.
Automotive Interior
RGB Lightguides and Ambient Lighting
Automotive
Backlit Switches and Panels
Consumer Electronics
RGB Indicators and Backlights
Lighting
Light Engines and Modules
Technical Specifications
| Parameter | Value | Notes |
|---|---|---|
| Channels | 3, 5, 6, 10 | Simultaneous measurement |
| Wavelength range | 460–650 nm | RGB LED range |
| Luminance range | 0.5–1,000 cd/m² | Min and max luminance |
| CIE xy accuracy | ±0.01 @ x=0.33, y=0.33 | Monochromatic and RGB colours |
| CIE xy repeatability | ±0.002 | Precision measurement |
| Intensity repeatability | < 1% | Excellent consistency |
| Dimensions (3–6 ch) | 105 × 55 × 50 mm | Compact design |
| Dimensions (10 ch) | 145 × 55 × 50 mm | Larger multichannel |
| Fiber length | 0.6 m | Per channel — polished |
| Fiber diameter | 2.2 mm incl. cladding | Larger aperture than 1mm fibre |
| Min. bend radius | 35 mm | 2.2mm fibre |
| Operating temperature | 0–50°C | Industrial range |
| Interface | USB, RS232, Daisy Chain | Up to 30 units per port |
| Supply voltage | 5.0V | USB bus powered |
| Supply current | 220 mA | Confirm with engineering |
| Output formats | Intensity, CIE xy, CIE u'v', DW, CCT | |
| Compatible optical heads | OH-12, OH-13, OH-14, OH6-RGB, OH3-RGB | 2.2mm POF heads — see optical heads page |
| Compliance | CE, RoHS | EU standards |
| Model numbers | 3-RGB · 5-RGB · 6-RGB · 10-RGB | Channel variants |
Feasa Software Suite
Included with every analyser
- Feasa Terminal — Direct command-line control and diagnostics
- Feasa User Software — Setup, calibration and pass/fail configuration
- Feasa Test Software — Production-line test execution and logging
- Feasa User Cal — User-side calibration management
- Real-time chromaticity display — XY chromaticity per channel with colour diagram overlay
- DLL/SDK — Programming examples in LabVIEW, C, C++, C#, Python
